The HK950FC wood grabber is a versatile and efficient tracked wood
grabber suitable for various appliions in agriculture and forestry.
Here are some key features and advantages of the machine:
- Environmental compliance: The engine of HK950FC complies with the
latest environmental standards, ensuring emission reduction and
increased sustainability.
- High quality hydraulic components: This machine is equipped with
hydraulic components from globally renowned brands, which can
provide reliable and efficient performance even under harsh
conditions.
- Powerful grip: HK950FC has strong grip and can safely handle heavy
objects such as hay bales, grain bags, logs, and wood.
- Wide operating range: With its wide range of functions, this
machine excels in various tasks, including stacking, loading,
unloading, and transportation. It is suitable for both agricultural
operations and forestry appliions.
- Excellent work efficiency: HK950FC aims to optimize work
efficiency, enabling operators to complete tasks quickly and
effectively. Its reliable performance and advanced features help
improve productivity.
The HK950FC wood grabber is a reliable, efficient, and versatile
solution for agricultural and forestry operations. Its powerful
grip, environmentally compliant performance, and high-quality
components make it an excellent choice for various tasks in these
industries.
Product Specifiion
Meet the Stage IV emission standards for diesel fuel for non-road
mobile machinery.
| Total width | mm | A | 2980 |
| Total height ( to top of cab ) | mm | B | 3046 |
| Counterweight Ground Clearance | mm | C | 1106 |
| Tail Swing Radius | mm | D | 3060 |
| Track Ground Length | mm | E | 3650 |
| Track length | mm | F | 4500 |
| Track Gauge | mm | G | 2380 |
| Undercarriage width | mm | H | 2980 |
| Track plate width | mm | I | 600 |
| Distance from slewing center to rear end | mm | J | 3050 |
| Grabber height | mm | K | 3246 |
| Maximum working height | mm | L | 15518 |
| Maximum unloading height | mm | M | 12272 |
| Bucket bar length | mm | N | 5501 |
| Boom length | mm | O | 9513 |
| Maximum working radius | mm | P | 14720 |
| Maximum gripping depth | mm | Q | 12144 |
| Maximum depth of small arm | mm | R | 8898 |
| Grabber height | mm | S | 3246 |
| Engine brand | 国四 | 1 | WP7H |
| Main pump flow rate | L/min | 2 | 220*2 |
*All product photos in this alogue are based on the actual product.
Product Construction
Engine : HEKUANG customized WP7H low-speed and high-torque engine, leading
the industry in thermal efficiency. The operating efficiency of the
whole machine is increased by 10%, and the fuel efficiency is
increased by 15%.
Main pump: Displacement increased by 8% compared with E generation and
competitors, electronically controlled main pump improves system
responsiveness and is more efficient.
Main valve: Exclusive custom-tuned main valve, internal flow channel
optimization, pressure loss reduced by 10%, better response.
Newly developed Laval intelligent operating system can realize
power system management, intelligent interaction, automatic
identifiion of working conditions, auxiliary operation,
personalized customization and other functions.
Operating system: The newly developed HEKUANG intelligent operating system can
realize power system management, intelligent interaction, automatic
identifiion of working conditions, auxiliary operation,
personalized customization and other functions.
1. Intelligent vehicle control : The driver can remotely control
the excavator by connecting the cell phone to the car's Bluetooth
to turn on/off the power, start/off the engine, turn on/off the air
conditioner, and turn on/off the lights.
2. Intelligent Multimedia : Driver can answer phone calls and play
music through the monitor after connecting his cell phone to the
vehicle's Bluetooth.
3. Intelligent Attachment : Selecting different attachment modes
through the screen can quickly realize the optimal matching of
attachments.
Cab: Adopting new structure, extending up to meet the requirements of
50 tons ROPS regulations, panoramic sunroof, breaking through the
concept of conventional construction machinery.
